Product Description
JBL EON712 – 12″ Inch PA Powered Speaker 1300W
The JBL EON712 is a 12″ Inch PA Powered Loud Speaker with Bluetooth. It is part of the JBL’s EON700 Series of powered PA Speakers. It brings professional-grade and unprecedented versatility to portable systems for live sound and fixed installation applications. The EON712 also offers class-leading volume and clarity with comprehensive features that make setup and operation a breeze.
Fidelity out of the box
The EON712 delivers superior coverage and stunning fidelity out of the box. This is possible with the upgraded custom JBL 2414H compression drivers and redesigned high-frequency horns. As a result, it is ideal for supporting any mid-sized indoor or outdoor event with loud, clear sound.
You can also dial in the perfect system sound in an instant with a built-in 3-channel mixer and dbx DriveRack Inside technology. The EON712 Automatic Feedback Suppression, 8-band output EQ and optimized use-case preset. You can access functions quickly and easily via a backlit colour LCD screen or the JBL Pro Connect app.
The EON712 offers Bluetooth 5.0 streaming, mounting options and built-in speaker delay that bring even more versatility to these rugged, reliable systems. As a result EON712 is are ideal for everyone from singer/ songwriters and event DJs to corporate AV providers and houses of worship.
EON712 Offers Unrivalled Power Performance
The EON712’s newly engineered acoustic package features a completely redesigned woofer, JBL’s powerful 2414H compression driver and an optimized horn. It all adds up to the superior JBL sound, with an incredible natural bass response and broad, even high-frequency dispersion.
The EON700 Series delivers robust sound reproduction that covers the needs of any mid-sized event, indoors or out. Furthermore, the EON712 is powered by 1,300 watts of ultra-efficient amplification for clean, clear sound at any volume level. And with 127 dB max SPL, you’ll deliver that front-row experience all the way to the back of the room.
Dial-Up Great Sound Fast With Pro-Grade DSP
The EON712 offers Pro-grade DSP with 8-band EQ and optimized use-case presets. Therefore it will have you sounding your best at the push of a button. Speaking to a crowd? You can use the ducking feature that will automatically lower the music when a mic signal is present. Keep your stage sound clean so your ears are protected with dbx Automatic Feedback Suppression, which stops the screech in its tracks.
Built-in Bluetooth 5.0 audio streaming takes advantage of the latest protocol performance for decreased latency, broader range and improved audio fidelity. Furthermore, two combo inputs and an XLR passthrough round out connectivity options. You can access speaker functions via an EasyNav LCD screen or use the universal JBL Pro Connect app to make adjustments from anywhere in the venue.
The EON712’s available yoke and pole-mounting accessories provide flexible configuration options so it lets you tailor your system for music venues, corporate events or worship services. And because speakers are stackable, they’re easier to store and transport so it makes transporting the EON712 easy.
Finally, like every JBL speaker, the EON712 loudspeaker undergoes 100 hours of rigorous testing to ensure it will perform flawlessly and consistently in real-world conditions.
- Custom-designed 12-inch woofer
- 2414H compression driver
- Redesigned high-frequency horn
- Power: 1,300W Peak / 650W RMS
- Frequency response: 50 Hz–20 kHz (-10 dB); 65 Hz–20 kHz (-3 dB)
- Max SPL: 127 dB
- Dispersion: 110° H x 60° V
- Audio I/Os: 2 XLR Combo, 1 XLR passthrough
- Advanced dbx DSP: Automatic Feedback Suppression, ducking, 100ms speaker delay, parametric EQ
- Built-in 3-channel digital mixer
- The backlit colour LCD screen provides easy access to functions
- Universal JBL Pro Connect app control
- Bluetooth 5.0 streaming and control
- Durable talc-reinforced polypropylene cabinet and metal grille
- Ergonomic handle simplifies transport
- Built-in pole mount and optional EON700 Universal Yoke Mount expand system configuration options
- Stackable cabinets allow easy storage
- Dimensions: 26.3 x 15 x 12.75 in (669 x 382 x 324 mm) (HxWxD)
- Weight: 32 pounds (14.5 kg)
- Shipping dimensions: 27.8 x 19.64 x 17.28 in (706 x 499 x 439 mm) (HxWxD)
- Shipping weight: 40.1 pounds (18.2 kg)
System Type: 12IN Powered Loudspeaker
Woofer Model: 712G
Woofer Size: 12″ Woofer
Magnet: Ferrite
Woofer Voice Coil: 2″
Tweeter Model: 2414H Compression Driver
Tweeter Size: 1″
Tweeter Magnet: Neodymium
Transducer Impedence: LF 4ohm rated, HF 8ohm rated
Max SPL: 127dB @1m/4Pi
Freq Range: -10 50Hz – 20kHz
Freq Range: -3 65Hz – 20kHz
Hor Dispersion: 100°
Vert Dispersion: 60°
Power Rating: 1300W peak / 650 RMS
AC Power Input: 100V-120V or 220V-240V
Cooling: Passive
LED Indicators: 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs
Input Impedence: 50k/100k un-balanced/balanced
Input Gain: -∞ to +36db
Crossover Freq: 2 kHz
I/O: 2 XLR Combo Jacks / BT 1 XLR M Thru
Cabinet: PP+10% Talc
Grille: 16GA perforated steel with acoustically transparent black cloth backing
Suspension/ Mount: 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes
Handles: 1, Cable channel on the bottom
Net Weight: 14.6kg (32.19 lbs.)
Gross Weight: 18.4kg (40.57 lbs.)
Product Dims HxWxL: 670 x 381 x 328 mm
Shipping Dims HxWxL: 684 x 490 x 430 mm
